DeWalt 5.0-HP 80-Gallon Single-Stage Air Compressor w/ High Flow (208-230V 1-Phase)

Model:

DXCM805.COM

Write A Review
$1,063.20
Was $1,329.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days

DeWalt 5.0-HP 80-Gallon Single-Stage Air Compressor w/ High Flow (208-230V 1-Phase)
DeWalt 5.0-HP 80-Gallon Single-Stage Air Compressor w/ High Flow (208-230V 1-Phase)
Model: DXCM805.COM
$1,063.20
Was $1,329.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Air Compressors Direct expert image
Expert Recommended Accessories Selected by Melissa, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Contractor

Style

Single Stage 1-Phase

CFM

14.6

Tank Size

80

  • High Flow 208/230V Single-Stage Air Compressor
  • Competes with two-stage compressors with equivalent PSI & CFM
  • Plenty of power to run a wide range of air tools & 70 dBA is ideal for indoor
  • Heavy-Duty 5.0 HP Belt-Drive Induction Motor
  • Better power transfer and longevity than direct drive units
  • Poly-v pulley and drive belt provide smooth operation with less vibration
  • i15 High Flow Twin Cylinder Pump
  • Cast iron, oil-lubricated pump with oil sight glass
  • Aluminum head and valve plate to maximize heat dissipation
  • High-grade stainless steel valves with superior o-ring seals to eliminate oil leaks
  • High-Efficiency Aluminum Flywheel
  • Balanced for best performance and durability
  • Allows maximum airflow and lower start-up amps due to less starting
  • Delivers 14.6 CFM at 90 PSI; Max 175 PSI
  • Max 175 PSI is typically found in two-stage compressors
  • Provides longer air tool run times with 80-gallon tank & 175 PSI
  • 80-Gallon ASME Tank
  • Easy-access manual drain simplifies routine maintenance
  • Tie-down holes on platform sides to secure unit when transporting
  • Convenient Controls
  • Equipped with pressure gauge and on/off switch
  • Perfect for a small shop, automotive enthusiast or serious DIY user
  • Limited Manufacturer Warranty
  • 2-year pump and 1-year on all other parts
  • Made In U.S.A.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

DXCM805.COM
specs product image PID-151549
General Information
Product Category
Air Compressor - Stationary
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter Learn More
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Amp Draw
20 Amps (230V)
Recommended Breaker
30 Amp Breaker
Engine
HP
5.0
Pump
CFM Learn More
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
14.6
CFM Rated @
90 PSI
CFM @ 40 PSI
17
Pump Material
Solid Cast Iron
Max PSI Learn More
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
175 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler Learn More
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off Learn More
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
80 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve Learn More
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Filter
Regulator
No
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Product Category
Air Compressor - Stationary
Weight
269 Pounds
Certification
ASME, CSA
Consumer Warranty
1 Year
Product Length
41 Inches
Product Width
25.4 Inches
Product Height
62.70 Inches
Power Type
Electric
UPC
45564647728
