Parker ZDHHT50 High Inlet 3/4" NPTF Refrigerated Air Dryer 10HP (60.6 CFM)

Model:

B004O0U5SE

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
View Ingersoll Rand High Temperature Refrigerated Air Dryer 10HP (35 CFM)
Model:
D60IT
$3,099.00
$2,789.10
Only 2 In-Stock
Parker ZDHHT50 High Inlet 3/4
Parker ZDHHT50 High Inlet 3/4" NPTF Refrigerated Air Dryer 10HP (60.6 CFM)
Model: B004O0U5SE
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Air Compressors Direct expert image
Expert Recommended Accessories Selected by Melissa, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Style

Refrigerated
  • Advanced 5-In-1 Drying System (115V 1-Phase)
  • Incorporates an aftercooler, 3.0 micron filter, condensate separator, precooler/reheater & evaporator
  • Eliminates the need for an aftercooler & additional piping
  • Suited for placement after reciprocating-type compressor
  • High Inlet Temperature
  • Handles temperatures up to 200°F (93° C)
  • ideal for body shops & paint booths
  • Environmentally Friendly
  • R134a refrigerant with no planned phase-out date
  • Air-To-Air Heat Exchanger
  • Reduces overall size of refrigeration circuit by up to 60%
  • Prevents condensation on downstream piping
  • Zero Air Loss Float Drain
  • Saving air saves energy and money
  • 115°F (46°C) Maximum Ambient Temperature
  • 232 PSI maximum inlet pressure
  • 40 CFM at 41°F; 50.1 CFM at 50°F; 60.6 CFM at 59°F
  • Capacities are based on 95°F ambient; 180°F inlet; 125 PSI
  • (Air flow correction factors are listed on attached spec sheet)
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

B004O0U5SE
specs product image PID-57952
Engine
HP
10
Air Dryer
Max Inlet Temp. Rating Learn More
Max Inlet Temp. Rating
The highest temperature the compressed air can be passing through the dryer for the dryer to operate properly and effectively
200
Max Ambient Temp. Rating Learn More
Max Ambient Temp. Rating
Ambient temperature is the air temperature of any object or environment where equipment is stored
115
Inlet Fittings
3/4"
Outlet Fittings
3/4"
Aftercooler
Yes
Post-Filter
Yes
Auto Drain Learn More
Auto Drain
Auto drain or drip leg drain used to drain air line of condensate and water
Yes
High Temp Learn More
High Temp
Dryers that are specifically designed to handle higher inlet temperatures than regular dryers. Typically paired with a piston or reciprocating air compressor
Yes
Overview
Weight
134 Pounds
Product Length
27.6 Inches
Product Width
13.9 Inches
Product Height
47.7 Inches
Additional Model Numbers

ZDHHT50, B004O0U5SE
