Eagle Silent Series 1.5-HP 6-Gallon Silent Oil-Free Pancake Air Compressor
Model:
EA-4500
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Melissa, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
Grade
Consumer
Style
Pancake
CFM
3.8
Tank Size
6
- Eagle 6-Gallon Portable Electric Air Compressor
- Ideal for multiple trim finishing nailers & general inflation
- Last up to 4X longer compared to most oil-fee air compressors
- Silent Series
- Runs at only 49 dbA @ 25 Ft.
- One-piece cover for sound reduction and jobsite protection
- Heavy Duty Induction Motor (120V)
- On / Off switch and plugs into standard 3-prong outlet
- Twin Cylinder, Oil Free Pump
- 2.5 CFM @ 40 PSI; 3.8 CFM @ 90 PSI; 150 PSI Max
- Low maintenance design for longer pump life
- Dual Top-View Gauges
- Easily monitor regulator and tank pressure
- 6-Gallon Pancake Tank
- Easy to move & transport at only 52 pounds
- Rubber isolation pads help reduce tank walk
- (2) 1/4" Regulated Air Couplers & Regulator Dial
- Easily supports 2 tools for efficiency
- Regulator dial makes this compressor simple to use
- 1-Year Limited Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
EA-4500
General Information
Product Category
Air Compressor - Portable
Engine
HP
1.5
Motor
Voltage
120 Volt AC
Phase
1-Phase
dBA
dBA
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
49
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
3.8
CFM Rated @
90 PSI
CFM @ 40 PSI
2.5
Pump Material
Aluminum
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
150 PSI
Pump Type
Single-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Direct Drive
Oil Type
Oil Free
Tank
Tank Size
6 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Product Category
Air Compressor - Portable
Weight
52 Pounds
Consumer Warranty
1 Year
Product Length
16 Inches
Product Width
16 Inches
Product Height
19 Inches
Power Type
Electric
UPC
20791505522
