Industrial Air 10-HP 120-Gallon Two-Stage Air Compressor (208-230V 1-Phase )

Model:

IV9919910.183

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Industrial Air 10-HP 120-Gallon Two-Stage Air Compressor (208-230V 1-Phase )
Industrial Air 10-HP 120-Gallon Two-Stage Air Compressor (208-230V 1-Phase )
Model: IV9919910.183
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Air Compressors Direct expert image
Expert Recommended Accessories Selected by Melissa, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Consumer

Voltage

208-230 Volt AC

Phase

1-Phase

CFM

35

Tank Size

120

  • Baldor Industrial Class Electric Motor
  • High quality 4 pole, 1725 RPM, UL certified, NEMA rated
  • Wires easily into your 208-230 volt, 1-phase system
  • Patented Cast Iron 2-Stage Pump Design
  • Delivers 35 CFM at 100 PSI; 33.6 CFM at 175 PSI
  • Provides for a cooler running pump & improves compression efficiency
  • Patented Asymmetrical Cooling Fins
  • Draws heat away from the precision bored cylinders
  • Patented Cast Iron Flywheel
  • Large, extended fins improve pump cooling & lower RPMs
  • Pre-Wired Magnetic Starter
  • Protects your compressor from being overloaded
  • 120 Gallon Vertical ASME Tank With Vibration Isolation Pads
  • Extended tank drain valve and ball valve for ease of use
  • Operates a wider range of tools & provides longer run time
  • Large Oil Sight Glass
  • Quickly check pumps oil level with ease
  • Extra capacity oil reservoir ensures lower oil
  • 2 Year Limited Factory Warranty
  • Purchase & use of maintenance kit doubles the pump warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

IV9919910.183
specs product image PID-80147
General Information
Product Category
Air Compressor - Stationary
Engine
HP
10
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter Learn More
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
Yes
Amp Draw
42
Recommended Breaker
60 Amp Breaker
Pump
CFM Learn More
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
35
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Max PSI Learn More
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler Learn More
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Tank
Tank Size
120 Gallons
Tank Included
Yes
Tank Outlet
3/4 Inch
Electronic Drain Valve Learn More
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Accessories
Air Dryer
No
Overview
Product Category
Air Compressor - Stationary
Weight
1025 Pounds
Certification
ASME, UL
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
51 Inches
Product Width
49 Inches
Product Height
84 Inches
Power Type
Electric
UPC
846212057056
