Ingersoll Rand 3-HP 8-Gallon Electric Dual Voltage Wheelbarrow Air Compressor (230V 1-Phase)
Model:
SS3J3-WB
+
Share This Product
Recommended Accessories

Expert Recommended Accessories
Selected by Melissa, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
Grade
Contractor
Style
Wheel Barrow
CFM
11.3
Tank Size
8
- 100% Cast-Iron Cylinders and Frame
- Designed for the toughest 100% continuous duty applications
- Long-lasting extended pump life designed for over 5,000 hours of trouble-free use
- Wheel Barrow Style
- Lightweight, low-profile design allows maximum maneuverability
- Heavy-duty 230-volt electric motor with user-friendly noise level
- Advanced Safety Features
- Enclosed belt guard provides constant protection
- Manual thermal overload prevents overheating for longer lifespan
- 8-Gallon Twin Tank
- Large wheel dampens vibration
- Manual tank drain for quick tank draining to prevent rust
- Top Mounted Control Panel
- Includes pressure switch, regulator and pressure gauge
- Dual quick connect allows more tools to run at the same time
- 1-Year Limited Factory Warranty
- Factory Warranty is 1 year; use premium quality petroleum product
- Extends to 2 years with purchase of IR All-Season Select Lubricant Start-Up Kit Model: 47853635001-R
- Oil is not included; sold separately
- American Pride
- Built in the U.S.A. of globally sourced components
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
SS3J3-WB

Engine
HP
3
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Amp Draw
14.7
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
11.3
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
135 PSI
Oil Sight Glass
No
Pump Type
Single-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
8 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Horizontal
Overview
Product Category
Air Compressor - Portable
Weight
175 Pounds
Certification
UL/CSA/ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
43 Inches
Product Width
18 Inches
Product Height
25 Inches
Power Type
Electric
UPC
663023030722
